DCM conveyor dismountable metal detector
The DCM metal detector detects ferrous, non-ferrous, and stainless steel contaminants in bulk materials on conveyor belts.
-
Easy Installation: Modular, dismountable design fits any conveyor without belt modifications.
-
High Sensitivity: Detects Fe ≥ 2.0 mm, non-Fe and stainless steel ≥ 4.0 mm.
-
Automated Response: Alerts and removes contaminated product or stops the line.
-
Rugged Build: Operates from -35°C to +40°C in demanding environments.
-
Equipment Protection: Prevents damage to processing machinery.
-
Touchscreen Control: 7″ display with multi-level access.
-
Material Memory: Stores settings for up to 10 products.
-
Certified: Complies with global safety and EMC standards.
Technical Data
| Model | Dimensions (LхWхH), mm | Max. power consumption, W | Weight, kg |
|---|---|---|---|
| DCM 800х250 | 1210х500х655 | 150 | 170 |
| DCM 800х400 | 1210х500х805 | 150 | 180 |
| DCM 800х600 | 1210х500х1005 | 150 | 190 |
| DCM 1000х400 | 1410х500х805 | 150 | 190 |
| DCM 1000х600 | 1410х500х1005 | 150 | 200 |
| DCM 1000х800 | 1410х500х1205 | 150 | 215 |
| DCM 1200х400 | 1610х500х805 | 150 | 205 |
| DCM 1200х600 | 1610х500х1005 | 150 | 215 |
| DCM 1200х800 | 1610х500х1205 | 150 | 225 |
| DCM 1400х400 | 1810х500х805 | 150 | 205 |
| DCM 1400х600 | 1810х500х1005 | 150 | 225 |
| DCM 1400х800 | 1810х700х1205 | 150 | 235 |
| DCM 1600х400 | 2010х700х805 | 150 | 225 |
| DCM 1600х600 | 2010х700х1005 | 150 | 240 |
| DCM 1600х800 | 2010х700х1205 | 150 | 250 |
| DCM 1600х1000 | 2010х700х1005 | 150 | 265 |
| DCM 1800х600 | 2210х700х1005 | 150 | 265 |
| DCM 1800х700 | 2210х700х1105 | 150 | 300 |
| DCM 2200х700 | 2610х700х1105 | 150 | 340 |
